4L80E AUTOMATIC OVERDRIVE TRANSMISSION AND KITS

4L80E Transmission and Kits

4L80E AUTOMATIC OVERDRIVE TRANSMISSION KIT DESCRIPTION

4L80E Automatic Overdrive Kit And Some Options

Mike Henderson, 1967 Camaro, Hughes Performance Powerglide and Converter

4L80E - The complete Automatic Overdrive with no-sweat installation that can be used for all makes and models, with adapter.

     Automatic overdrive transmissions have become “the”setup for the future. This technology allows the use of steep gears for performance while not interfering with highway cruising and fuel mileage, thanks to the big rpm reduction that their Fourth gear overdrive provides.
     Does your engine produce high horsepower and torque numbers due to nitrous or a supercharger, and it’s exceeding the capabilities of the 200-4R or the 700-R4? Maybe it’s time to consider the GM 4L80E electronically controlled four-speed transmission.
     In street applications, the fuel savings alone are probably worth the price of an overdrive, especially if you’re running a big-block. And the wear and tear on your engine is reduced, since the overdrive will have you cruising at about 1,000 rpm less on the highway.
     The 4L80E transmission is original equipment for all heavy-duty GM truck applications. It’s GM’s latest offspring of the TH400 trans, and we all know how tough that piece is. With GM’s latest refinements and electronic controls, the 4L80E is stronger and much smarter than its TH400 predecessor, even with its Fourth-gear overdrive. When modified for all-out performance, the way the Hughes Performance Street/Strip 4L80E is, the 4L80E stands alone as the ultimate setup for extreme-performance.
     And because we can program this electronically controlled transmission to suit your specific needs, you can have hard-hitting drag-race-type shifting at full throttle but also reliable part-throttle street manners GM has designed into the unit. Now more then ever before, is the era you can build your hot rod, custom car or truck, or maybe that street machine you’ve always wanted, and have a state-of-the-art transmission assembly. Hughes Performance’s continued research and development allows you to have the best, most reliable and longest lasting transmission and converter kit with the latest technology available on the market today! Call our experts today and understand why Hughes should be your only source for automatic transmissions, torque converters, and related components. Hughes really does care!
     The thought of installing an electronically controlled transmission might be intimidating for some. But wait a minute. Installing one of the transmissions with the electronic hardware really is simple. Hughes furnishes all the optional necessary hardware to make this installation a snap, including a foolproof stand-alone computer. You can even utilize the OE column shifter, or, for floor-mounted applications, the Performance’s Mega Shifter can be installed for 4-on-the-floor. Hughes now ships the programmer with the optional control unit to facilitate program changes quickly.

Note: The Transmission TCM Computer Kit 25-100, the Speedometer Controller for installing 4L80E in older vehicles with mechanical speedometers 25-150, etc., are not included with these kits. They have to be purchased separately. This, along with rewording their description above some, is to clarify the somewhat misleading description of these kits provided by Hughes in their catalog. These kits only include what is listed below under “Transmission Assemblies”.

4L80E AUTOMATIC OVERDRIVE TRANSMISSION KITS, PARTS, COMPONENTS, ACCESSORIES

The 4L80E Automatic Overdrive Set Up	Part No.
Transmissions
Heavy Duty Transmission, Street/Strip, Automatic, 91-95, 2WD Electronically Controlled 4-Speed Transmission.	25-1
Heavy Duty Transmission, Street/Strip, Automatic, 1996-On, 2WD Includes Transmission, Snap in Cooler Lines, “Long” Manual Shaft.	25-1A
Heavy Duty Transmission, Street/Strip, Automatic, Truck, 91-95, 4WD Electronically Controlled 4-Speed Transmission.	25-1C
Heavy Duty Transmission, Street/Strip, Automatic, Truck, 1996-On, 4WD Includes Transmission, Snap in Cooler Lines, “Long” Manual Shaft.	25-1CA
Heavy Duty Transmission, Street/Strip, Full Manual, 91-95, 2WD Electronically Controlled 4-Speed Transmission.	25-2
Heavy Duty Transmission, Street/Strip, Full Manual, 1996-On, 2WD Includes Transmission, Snap in Cooler Lines, “Long” Manual Shaft.	25-2A
Heavy Duty Transmission, Street/Strip, Full Manual, Truck, 91-95, 4WD Electronically Controlled 4-Speed Transmission.	25-2C
Heavy Duty Transmission, Street/Strip, Full Manual, Truck, Truck, 1996-On, 4WD Includes Transmission, Snap in Cooler Lines, “Long” Manual Shaft.	25-2CA
Transmission Assemblies (Kits)
Heavy Duty Transmission Street/Strip or Tow Package, 1991-1995, 2WD Includes 25-1 Transmission, 25LXTM L/U HD Lock-up Tow Converter, HP2580 Deep Aluminum Pan Kit installed on transmission for more oil capacity, and 20,000 GVW Transmission Oil Cooler. Built for “short” manual shaft applications.	K25-10X
Heavy Duty Transmission Street/Strip or Tow Package, 1991-1995, 2WD (Diesel) Includes 25-1 Transmission, 25LXTM L/U HD Lock-up Tow Converter, HP2580 Deep Aluminum Pan Kit installed on transmission for more oil capacity, and 20,000 GVW Transmission Oil Cooler. Built for “short” manual shaft applications. DIESEL	K25-10XD
Heavy Duty Transmission Street/Strip or Tow Package, 1996-on, 2WD Includes 25-1A Transmission, 25LXTM L/U HD Lock-up Tow Converter, HP2580 Deep Aluminum Pan Kit installed on transmission for more oil capacity, and 20,000 GVW Transmission Oil Cooler. Built for “long” manual shaft applications.	K25-10XA
Heavy Duty Transmission Street/Strip or Tow Package, 1996-on, 2WD (Diesel) Includes 25-1A Transmission, 25LXTM L/U HD Lock-up Tow Converter, HP2580 Deep Aluminum Pan Kit installed on transmission for more oil capacity, and 20,000 GVW Transmission Oil Cooler. Built for “long” manual shaft applications. DIESEL	K25-10XDA
Heavy Duty Transmission GM Performance, 2WD Includes 25-1 Transmission, 25-30L High Performance Lock-up 10” 3,000 Stall Billet Cover Torque Converter, HP2580 Deep Aluminum Pan Kit installed on transmission for more oil capacity, and HP8235 20,000 GVW Transmission Oil Cooler.	K25-10G
Heavy Duty Transmission Ford Performance, 2WD Includes 25-1 Transmission, 53-30L Custom Built 3,000 Stall Lock-up Converter With Billet Cover. Also includes Adapter Plate Kit for Ford engine, Deep Aluminum Pan, and 20,000 GVW Transmission Oil Cooler. (This kit has been discontinued, but you can still use K25-10X and buy the Adapter Plate Kit separately.)	K25-10F
Parts & Components
Transmission Valve Body Reprogramming Kit	HP2505
Transmission Valve Body Manual Reprogramming Kit	HP2506
Transmission Valve Body Reprogramming Kit With Video	HP2507
Transmission Full Manual Valve Body	HP2510
Locking Filler Tube Assembly	HP2535
Transmission Thrust Washer Kit (No Selectives)	HP2536
Transmission Bushing Kit	HP2537
4L80E Transmission Bushing Kit 1997-on	HP2537A
Transmission Thrust Bearing Kit (4 Bearings)	HP2538
Premium Direct / Forward Race Fictions	HP2540
Premium Direct / Forward Kevlar Race Fictions (Discontinued)	HP2540K
Direct Clutch Kolene® Steel	HP2541K
Premium Intermediate Race Friction	HP2542
Intermediate Clutch Kolene® Steel	HP2543K
Premium 4th Clutch Race Friction	HP2544
4th Clutch Kolene® Steel	HP2545K
Premium Overrun Clutch Race Friction	HP2546
Forward Clutch Kolene® Steel	HP2547K
Premium Intermediate Race Friction (.061”)	HP2548
Premium Forward/Direct Clutch Kit. Includes 6 premium (.061”) Red Friction, 6 Steels (.061”).	HP2550
Front Kevlar Race Band	HP2551H
High Static Rear Band	HP2552
Rear Kevlar Race Band	HP2552H
Custom EXT. Housing Early Model Installation for Mechanical Speedometer	HP2570
Transmission Planetary Gearset with 2.75 Low Gear	HP2575
34 Element Heavy Duty Sprag Assembly	HP2579
Deep Aluminum Oil Pan Kit, 4 Quarts Extra Capacity	HP2580
Transmission Service Kit	HP2585
4L80E Transmission Service Kit 1997-on	HP2585A
Basic Overhaul Race Kit	HP2586
4L80E Transmission Basic Overhaul Race Kit 1997-on	HP2587
Premium Overhaul Race Box Kit	HP2588
Premium Overhaul With Kolene® Steels	HP2588K
4L80E Premium Overhaul Race Box Kit 1997-on	HP2589
4L80E Premium Overhaul Race Box Kit With Kolene® Steels 1997-on	HP2589K
Master Overhaul Race Box Kit	HP2591
4L80E Master Overhaul Race Box Kit 1997-on	HP2592
4L80E Accessories
Transmission TCM Computer Kit (Supercedes 25-110, 25-150, 25-160, 25-170, 25-171, 25-180, and 25-190). Includes all that is needed for use with electronic speedometer. Note: You must also purchase 25-150 for use with mechanical speedometer.	25-100
Programmer for 25-100 Controller Note: Discontinued, use 25-100.	25-110
Speedometer Controller for installing 4L80E in older vehicles with mechanical speedometer. Use with 25-100.	25-150
Main Wiring Harness Note: Discontinued, use 25-100.	25-160
Vehicle Harness Adapter, Analog Note: Discontinued, use 25-100.	25-170
Vehicle Harness Adapter, Digital Note: Discontinued, use 25-100.	25-171
Transmission Control Module (TCM) Note: Discontinued, use 25-100.	25-180
TCM Chip Note: Discontinued, use 25-100.	25-190
4L80E Torque Converters
Torque Converter 2,000 Stall¹ Rated, 1991-on 4-Speed Electronic O/D Lock-up²	25-20L
Torque Converter 2,500 Stall¹ Rated Lock-up, 1991-on 4-Speed Electronic O/D Lock-up²	25-25L
Torque Converter 3,000 Stall¹ Rated Lock-up, 1993-on 4-Speed Electronic O/D Lock-up²	25-30L
Torque Converter 3,500 Stall¹ Rated Lock-up, 1993-on 4-Speed Electronic O/D Lock-up²	25-35L
Torque Converter Fuel Miser Lock-up, 1991-on 4-Speed Electronic O/D Lock-up²	25LFuel
Torque Converter Tow Master Lock-up, 1991-on 4-Speed Electronic O/D Lock-up²	25LTow
Torque Converter Heavy Duty Tow Master Lock-up (Diesel), 1991-on 4-Speed Electronic O/D Lock-up²	25LXFM
Torque Converter Heavy Duty Tow Master Lock-up, 1991-on 4-Speed Electronic O/D Lock-up²	25LXTM
Note¹: All Stall speeds are approximate ratings for fresh big-block engines, small-block engines will vary 300 to 500 RPM’s lower. All stall ratios will vary according to your specific application. Specialty custom units for tractor pull, monster truck, nitrous or super charged applications, will result in minor additional charges due to extra time and materials required. Note²: Due to computer controlled electronics, Non-Lock-up converters are not recommended for these applications.
